Pairing Mini

Follow the procedure below to pair a Mini series Transmitter (Remote) with a Receiver.

This process enables a 10 second pairing period.

1 - Disconnect the +ve power to the Receiver.

2 - Press the RED STOP button on the Transmitter.

3 - Press and Hold both the RED STOP button and the GREEN ON buttons until the LED

turns off.

4- Reconnect the +ve power to the Receiver. (This begins the 10 second pairing period - the Red LED will be flashing.)

5 - Within 10 seconds press and HOLD the GREEN ON button until the Transmitter LED
remains on, or until the Receiver Status LED is continuously on. This completes the pairing.‍

‍8 - Test the pairing by pressing the GREEN ON button to turn the Transmitter ON then press each of the function buttons.

‍

‍
